輔助設備系列
自動對缐剖布機
閱讀次數：13412 24/08/2018
本機特性
解決布匹在染色水冼所形成無法避免的捻狀困擾及剖缐歪斜不準造成布匹的重大損耗。
功能為:
(1)圓筒針織布自動對線剖開整齊擺布
(2)剖開布匹展開整齊擺布。
本機型可獨立操作進行自動對缐剖開工作，亦可與后整理機連結。
CHARACTE RISTICE
In order to resolve the Unavoidable disturbance of rope to be formed after the washing and rope dyeing of fabrics and the fabrics great loss resvlting from the tilt over and inaccuracy of the slitting.
The functions of this machine are:
1、Tubular knitted fabrics trace and slit automatically and delivery to be plaiting.
2、Open width fabrics after dyeing to untwist and delivery to be plaiting.
This machine can be operated individvally to proceed auto trace slitting work;aslo,can be connected to another finishing machine(Suvh as :Drying ,setting processing....etc)
解決布匹在染色水冼所形成無法避免的捻狀困擾及剖缐歪斜不準造成布匹的重大損耗。
功能為:
(1)圓筒針織布自動對線剖開整齊擺布
(2)剖開布匹展開整齊擺布。
本機型可獨立操作進行自動對缐剖開工作，亦可與后整理機連結。
CHARACTE RISTICE
In order to resolve the Unavoidable disturbance of rope to be formed after the washing and rope dyeing of fabrics and the fabrics great loss resvlting from the tilt over and inaccuracy of the slitting.
The functions of this machine are:
1、Tubular knitted fabrics trace and slit automatically and delivery to be plaiting.
2、Open width fabrics after dyeing to untwist and delivery to be plaiting.
This machine can be operated individvally to proceed auto trace slitting work;aslo,can be connected to another finishing machine(Suvh as :Drying ,setting processing....etc)
| 周邊設備 PERIPHERAL EUIPMENT | |||||||||
| ItemMode | A | B | C | D | E | F | 機械速度Machine Speed | 總馬力Power |
A.自動剖開設備 Automatic slitting device B.迴轉盤設備 Whirling table device C.自動解撚器 Untwister device D.壓軋裝置 Squeezing mangle E.自動對中展開設備(含打布器)Auto expanding & centering device(Including beater device) F.大型軋液機 Padder machine |
| 2p1 | √ | 15-38M/Min | 6HP | ||||||
| 2p2 | √ | √ | √ | 15-60Min | 7HP | ||||
| 2p3 | √ | √ | √ | √ | 15-60Min | 9HP | |||
| 2p4 | √ | √ | √ | √ | 15-80Min | 9HP | |||
| 2p5 | √ | √ | √ | √ | √ | 15-60Min | 11HP | ||
| 2p6 | √ | √ | √ | √ | √ | 15-80Min | 28HP | ||
| 規格說明 SPECIFICATION | |
| 工作寬度 Working Width | 2000mm-2600mm(optional) |
| 氣壓來源 Compressed Air | 6kg/cm2 |
